| Nazwa marki: | Womeng |
| Numer modelu: | WM-AMD01 |
| MOQ: | 1 |
| Ceny: | $800,000.00-$9500,000.00 |
| Szczegóły opakowania: | Zdatne do żeglugi drewniane pudełko |
| Warunki płatności: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Product Info
|
Product size
|
40m*6m*4m(for reference only)
|
|
Product structure
|
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
|
Control system
|
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
|
|
Drive system
|
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
|
|
Tension system
|
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor. |
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
|
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
|
Materials corrective system
|
Materials corrective system: Adopt international famous brand deviation correction system |
|
Power
|
380V, 50HZ three phase five wire
|
|
Machine Capacity
|
400KW (Excluding glue machine and air compressor)
|
|
Bleed pressure
|
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
|
| Machine weight | 100 Tons approximately |
Technical features
* Compact design, easy operation & maintenance
* Modular design, for future upgrading
* Low consumption, high efficiency
* Servo or frequency inverter transmission
* Touch screen for man-machine conversation
* Auto record and calculation of process data
* Main raw material auto splicing at zero speed
* Inverter or servo unwinding with tension control
* Web guiding controller
* Sensor quality control systems
* Material broken and lost inspection, auto machine stops and defective products auto rejection
* Easy size changing and manufacture
Whatsapp: +008615805080212
https://www.diapersmachines.com
The core quality is stable and directly addresses the core pain points of women during their menstrual period
Leak-proof and snug dual protection, enhancing the sense of security when wearing
The full servo system precisely controls the stretching tension of the elastic waistline and the heat pressing parameters of the leak-proof edge, ensuring that the pants closely fit the waistline and hip curve during menstruation, and do not shift or curl during movement. The core is evenly laid out, and the proportion of the fluff slurry and water-absorbing resin is precisely mixed. 300ml of simulated menstrual blood can quickly penetrate and lock in water, with a dry surface and no reverse seepage. Equipped with a double-layer leak-proof bottom film process, the side leakage and rear leakage rates are less than 2%, fully meeting the needs of all scenarios such as sleeping soundly at night and engaging in activities during the day.
Skin-friendly, comfortable and compatible, caring for sensitive skin
Compatible with various skin-friendly surface layers such as pure cotton, bamboo fiber, and breathable non-woven fabric, as well as environmentally friendly materials like degradable PLA base film. The servo system precisely controls the tension of fabric delivery, preventing fiber damage during production, ensuring that the pad feels soft and smooth to the touch, and reducing skin friction and irritation during menstruation. Supports the production of ultra-thin (2-3mm) and thickened (4-5mm) cores, and can meet the ventilation requirements of tropical regions and the insulation needs of high-latitude regions without equipment modification.
Global landing friendly, lowering the threshold for cross-regional operations
The raw materials have strong compatibility with the site
It has an extremely wide range of adaptability to core raw materials. Economical non-woven fabrics from Southeast Asia, degradable bottom films from Europe, and super absorbent resins from the Middle East can all be directly put into production without the need to modify equipment. The production line adopts a modular design, with a minimum floor area of only 70 square meters. It can be flexibly laid out according to the shape of the factory building and is suitable for the site conditions of small and medium-sized factories in emerging markets.
Deal with complex production environments
It supports a wide voltage input range of 180V to 380V, capable of handling ±20% instantaneous voltage fluctuations without the need for additional voltage stabilizers. It is particularly suitable for regions with unstable power supply such as Africa and South Asia. The key components are designed to be dust-proof and moisture-proof, and can operate stably within a temperature range of -10 ℃ to 45℃ and a humidity range of 30% to 90%, adapting to different climatic conditions such as high humidity in Southeast Asia and high temperature in the Middle East.
The logistics and transportation are convenient, reducing the landing cost
After modular disassembly, each individual module is compact in size and controllable in weight, and can be directly adapted to container transportation without the need for special logistics tools. Compared with traditional integrated production lines, cross-border logistics costs are reduced by 20% to 30%, making it particularly suitable for regions with high logistics costs such as Africa and Latin America.
